Goldring E3 Moving Magnet Cartridge

$180.00

The Goldring E Series cartridges feature a dual magnet arrangement. Magnetic Duplex Technology uses two low mass magnets which interact only with their partnering pickup coil, angled at 45 ̊ to match the cutting head arrangement. This enables the cartridges to more accurately trace the record groove because they precisely emulate the geometry of the cutting head, “making for better stereo separation and a more accurate, involving and musical soundstage”.
The E3 cartridge features the same aluminium cantilever as the E2, but benefits from a superior, bonded, super-elliptical (0.3 x 0.7 mil)...

Buy this from our eshop at

1 In Stock

Compare
SKU: 5036694030967 Category: Product Brand:
Brand:
Goldring E3 Moving Magnet Cartridge

    Description

    The Goldring E Series cartridges feature a dual magnet arrangement. Magnetic Duplex Technology uses two low mass magnets which interact only with their partnering pickup coil, angled at 45 ̊ to match the cutting head arrangement. This enables the cartridges to more accurately trace the record groove because they precisely emulate the geometry of the cutting head, “making for better stereo separation and a more accurate, involving and musical soundstage”.

    The E3 cartridge features the same aluminium cantilever as the E2, but benefits from a superior, bonded, super-elliptical (0.3 x 0.7 mil) stylus. This gives it better high frequency detail retrieval over ordinary elliptical (0.4 x 0.7 mil) or spherical (0.6 mil) types due to its smaller front-to-back radius. The main effect is the reduction of sibilance, especially in high level vocal recordings.

    Specifications

    Colour: Violet
    Cantilever: Aluminium
    Stylus profile: Elliptical
    Stylus radius: 0.3 x 0.7 mil
    Frequency range: 20 Hz – 20 kHz
    Channel balance: 1.5 dB at 1 kHz
    Channel separation: >20 dB at 1 kHz
    Sensitivity: 3.5 mV (1 kHz @ 5 cm/sec)
    Static compliance: 20 mm/N
    Vertical tracking angle: 20°
    Load resistance: 47 k
    Load capacitance: 100 – 200 pF
    Internal inductance: 400 mH
    Internal resistance: 410
    Cartridge mass: 6.9 g
    Fixing centres: 12.7 mm (0.5 in)
    Playing weight: 1.5 g – 2.5 g (2.0 g recommended)
